BARR Plastics offers the GRAF EcoBloc system, a modular solution for stormwater retention and detention. Each EcoBloc module has a gross volume of 225 liters (59.4 US gallons) and a reservoir volume of 217 liters (57.3 US gallons), providing a 96% storage coefficient. These modules can be stacked up to 13 layers high, allowing for installation depths of up to 5 meters (16.4 feet). For projects requiring greater depths, the EcoBloc Inspect Ultra modules can be installed at depths up to 7.5 meters (24.6 feet). If installation beyond 7.5 meters is necessary, approval from GRAF can be sought to accommodate specific project requirements. This design enables the construction of systems with capacities ranging from a few hundred gallons to several thousand gallons, tailored to specific project requirements.

For detailed information and assistance in configuring a system that meets your specific needs, it's recommended to contact a BARR Stormwater components specialist.

The GRAF EcoBloc system is engineered to withstand heavy loads, including vehicular traffic, ensuring durability and reliability in various applications. Key features contributing to its robustness include:

• High Load-Bearing Capacity: The EcoBloc modules are designed to support substantial weights. For instance, the GRAF EcoBloc Inspect flex has a heavy-duty load-bearing capacity of up to 60 tons (HS-25) with a minimum earth covering of 800 mm (31.5 inches).
• Installation Depth Flexibility: These modules can be installed at depths of up to 5 meters (16.4 feet), even under heavy loads, allowing for up to 13 layers of stacking.
• Durable Design: Constructed with high-quality materials, the EcoBloc system is designed for a service life exceeding 50 years, ensuring long-term performance and sustainability.

By adhering to recommended installation guidelines, including appropriate earth covering and proper stacking, the GRAF EcoBloc system provides a robust solution capable of handling heavy vehicular loads in stormwater management applications.

Yes, the GRAF EcoBloc system is designed for seamless integration with existing stormwater management infrastructure. Its modular design and versatile connection options allow it to adapt to various project requirements, enhancing or expanding current systems effectively.

Key Features Facilitating Integration:

• Versatile Pipe Connections: The EcoBloc system accommodates a wide range of pipe diameters, with connection surfaces up to DN 400 (approximately 16 inches). This flexibility ensures compatibility with existing pipelines, facilitating straightforward integration.
• Modular and Scalable Design: Each EcoBloc module has a gross volume of 205 liters (54.2 US gallons) and can be stacked up to 14 layers high, allowing for installation depths of up to 5 meters (16.4 feet). This modularity enables customization to meet specific capacity and spatial requirements, making it suitable for both small-scale and large-scale applications.
• Integrated Access Shafts: The system features the Ecobloc Inspect Smart Plus Shaft, which provides easy access for inspection and maintenance. This shaft can be positioned flexibly within the EcoBloc system, allowing for convenient monitoring and upkeep without disrupting existing infrastructure.
• High Load-Bearing Capacity: Designed to withstand heavy loads, the EcoBloc system supports up to 60 tons (HS-25) with appropriate earth covering. This robustness ensures durability and reliability, even when integrated into areas subjected to vehicular traffic.

By incorporating these features, the GRAF EcoBloc system offers a flexible and efficient solution for enhancing existing stormwater management infrastructure, addressing challenges such as increased runoff, regulatory compliance, and space constraints.

Yes, BARR Plastics offers comprehensive technical support and consultation services during both the planning and installation phases of your stormwater management projects. Their services include:

• Design Assistance: Expert guidance in designing stormwater attenuation and soakaway systems tailored to your project's specific requirements.
• Installation Support: Experienced professionals provide reliable support to ensure smooth implementation and long-term performance of your stormwater systems.

For personalized assistance, you can contact BARR Plastics at +1-800-665-4499 or via email at info@barrplastics.com.

The GRAF EcoBloc system is engineered to meet rigorous quality standards and holds several notable certifications, ensuring its reliability and performance in stormwater management applications. Key certifications and standards include:

• British Board of Agrément (BBA) Certification: The EcoBloc Inspect flex and EcoBloc maxx units have been awarded BBA Agrément Certificates, confirming their compliance with UK Building Regulations and suitability for use in stormwater attenuation and infiltration systems.
• ISO 9001:2008 Quality Management System: The manufacturing processes for GRAF EcoBloc products are certified under the ISO 9001:2008 standard by DEKRA (Certificate 80613353), demonstrating a commitment to consistent quality and continuous improvement.

These certifications underscore the GRAF EcoBloc system's adherence to international quality and performance standards, making it a reliable choice for effective stormwater management solutions.

Yes, BARR Plastics provides personalized support to their clients, ensuring a dedicated point of contact throughout your project. Their team of experts offers comprehensive assistance during both the planning and installation phases, tailoring solutions to meet your specific project requirements and site conditions. For more information or to discuss your project needs, you can contact BARR Plastics at +1-800-665-4499 or via email at info@barrplastics.com.
