Narrow Profile Storage Tanks
Aligned to the side of your house, our narrow profile tanks are perfect for those wanting to collect a ton of rain in a smaller amount of space. 3 sizes are available in opaque forest green colour that blocks out sunlight, thereby preventing algae growth within the tank. This style of tank is available in white as well, in a variety of sizes ranging from 250 USG to 1000 USG sizes all are 31 wide or less (except for the 1000 gal. size at 40") and designed to fit through a standard doorway and also fit nicely against walls and into corners while still providing a stable self-supporting base. Freestanding and self-supporting - no need for steel support frame except for 41015. Tanks can be connected together at the bottom to add capacity.
Add a Rain Harvesting pre-filter and first flush diverter and accessories to connect your roof gutter to your tank and clean the rainwater before it reaches the tank and start collection and use of rainwater right away.
BARR has a variety of other accessories for your system, such as pumps, level gauges, hose, fittings, piping , etc.
Aligned to the side of your house, our narrow profile tanks are perfect for those wanting to collect a ton of rain in a smaller amount of space. 3 sizes...
Aligned to the side of your house, our narrow profile tanks are perfect for those wanting to collect a ton of rain in a smaller amount of space. 3 sizes are available in opaque forest green colour that blocks out sunlight, thereby preventing algae growth within the tank. This style of tank is available in white as well, in a variety of sizes ranging from 250 USG to 1000 USG sizes all are 31 wide or less (except for the 1000 gal. size at 40") and designed to fit through a standard doorway and also fit nicely against walls and into corners while still providing a stable self-supporting base. Freestanding and self-supporting - no need for steel support frame except for 41015. Tanks can be connected together at the bottom to add capacity.
Add a Rain Harvesting pre-filter and first flush diverter and accessories to connect your roof gutter to your tank and clean the rainwater before it reaches the tank and start collection and use of rainwater right away.
BARR has a variety of other accessories for your system, such as pumps, level gauges, hose, fittings, piping , etc.
Couldn't load pickup availability
Height: " | Width: " | Length: "
| Capacity | Part # / Drawing | Dia./ Width (in) |
Length (in) |
Height (in) |
Lid/Fill Opening (in) |
Fitting | Weight (lbs) | Availability | |||
|---|---|---|---|---|---|---|---|---|---|---|---|
| USG | IG | LTR | Premium Weight 1.5-1.7 SG | Heavy Weight 1.9 SG | |||||||
| 140 | 115 | 522 | 41205 Sq. Vert. | N/A | 24" | 24" | 60" | 16" | 1-1/4" | E | |
| 250 | 208 | 946 | 42337 | N/A | 29" | 62" | 40" | 16" | 1-1/4" | 103 | |
| 275 | 230 | 1045 | *41199 Frame Incl. | N/A | 24" | 48" | 60" | 16" | No Ftg. | E | |
| 250 | 208 | 946 | SP0250-UT-G (Green) | N/A | 29" | 62" | 42" | 16 | 1-1/4" | 113 | WA |
| 300 | 250 | 1136 | 44944 | N/A | 29" | 61.5" | 47" | 16 | 1-1/4" | E | |
| 300 | 250 | 1136 | SP0300-UT-G (Green) | N/A | 29" | 62" | 53" | 16 | 1-1/4" | 159 | WA |
| 400 | 330 | 1500 | 41190 Ribbed | N/A | 32" | 44" | 83" | 16" | 1-1/4" | E | |
| 400 | 330 | 1500 | 44361 - DK GRN | N/A | 29" | 64" | 67.5" | 16" | 1-1/4" | WA | |
| 400 | 330 | 1514 | SP0400-UT-G (Green) | N/A | 29 | 62 | 65 | 16 | 1-1/4" | 207 | WA |
| 400 | 330 | 1514 | 43856 | N/A | 29" | 70" | 66" | 16" | 1-1/4" | N/A | WA New |
| 400 | 330 | 1514 | 44280 - BLK | N/A | 29" | 62" | 64" | 16" | 1-1/4" | 183 | E |
| 400 | 330 | 1514 | 41241 | N/A | 29" | 62" | 64" | 16" | 1-1/4" | 183 | E |
| 420 | 350 | 1590 | *41015 Frame Incl. | N/A | 30" | 61" | 64" | 16" | No Ftg. | E | |
| 500 | 416 | 1893 | 43616 | N/A | 31" | 74" | 70" | 16" | 1-1/4" | N/A | WA |
| 500 | 416 | 1893 | 44945 | N/A | 31" | 74" | 68" | 16" | 1-1/4" | N/A | E |
| 1000 | 830 | 3800 | 44045 | N/A | 40" | 92" | 84" | 16" | 1-1/4" | N/A | WA |
